Product Details
Place of Origin: CHINA
Brand Name: FSK / FAG / TIMKE / NTN / NSK / KOYO / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: NN3009KP4
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Let's Chat in Detail
Packaging Details: 1.Industrial packaging: plastic bag + kraft paper + carton + plywood pallets; plastic tube + carton + plywood pallets; 2. Commercial packing: 1pc/plastic bag + color box + carton + plywood pallets 3. As the clients' requirement
Delivery Time: 3 Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/day
Model No.: |
NN3009KP4 |
Size: |
45 × 75 × 23mm |
Weight: |
0.4kg |
Cage: |
Brass Cage / Steel Cage |
Advantage: |
Low Vocie,high Speed, Long Life |
Character: |
Short Roller |
Model No.: |
NN3009KP4 |
Size: |
45 × 75 × 23mm |
Weight: |
0.4kg |
Cage: |
Brass Cage / Steel Cage |
Advantage: |
Low Vocie,high Speed, Long Life |
Character: |
Short Roller |
Small Size Full Complement Cylindrical Roller Bearings For Machine Shaft
Cylindrical Roller Bearings Description
N design The inner ring has two integral flanges and NU design The outer ring of bearings of the NU design has two integral flanges and the inner ring is without flanges. Axial displacement of the shaft with respect to the housing can be accommodated in both directions within the bearing itself.
NJ design The outer ring has two integral flanges and the inner ring one integral flange. The bearings are therefore suitable for the axial location of a shaft in one direction.
NF design The outer ring has one integral flange and the inner ring two integral flanges.
NP design The outer ring has one integral flange and one non-integral flange in the form of a loose flange ring and the inner ring two integral flanges.
NUP design The outer ring has two integral flanges and the inner ring one integral flange and one non-integral flange in the form of a loose flange ring. The bearings can be used as locating bearings, i.e. they can provide axial location for a shaft in both directions.
RN design No outer ring and the inner ring two integral flanges.
Bearing Specification :
|
Model Number |
NN3009KP4 |
|
Part Name |
Cylindrical Roller Bearings |
|
Brand |
FSK / FAG / TIMKE / NTN / NSK / KOYO / OEM |
|
Precision Rating |
ABEC-1 to ABEC-9 |
| Vibration and Noise | Z0V0 / Z1V1 / Z2V2 / Z3V3 |
| Material | Gcr15 Chrome Steel |
| Number of Row | Double Row |
| Cage | Brass Cage / Steel Cage |
|
Dimensions(mm)(d*D*b) |
45 × 75 × 23mm |
|
Weight / Mass ( KG ) |
0.4kg |
|
HS Code |
8482800000 |
| Original Country Show | CHINA |
Bearings Detailed Pictures :
Part of Thrust Cylindrical Roller Bearings List:
| Bearing No. | ID mm | OD mm | Width mm | Mass kg | |
| NN3005 | NN3005K | 25 | 47 | 16 | 0.127 |
| NN3006 | NN3006K | 30 | 55 | 19 | 0.198 |
| NN3007 | NN3007K | 35 | 62 | 20 | 0.258 |
| NN3008 | NN3008K | 40 | 68 | 21 | 0.309 |
| NN3009 | NN3009K | 45 | 75 | 23 | 0.0407 |
| NN3010 | NN3010K | 50 | 80 | 23 | 0.436 |
| NN3011 | NN3011K | 55 | 90 | 26 | 0.647 |
| NN3012 | NN3012K | 60 | 95 | 26 | 0.693 |
| NN3013 | NN3013K | 65 | 100 | 26 | 0.741 |
| NN3014 | NN3014K | 70 | 110 | 30 | 1.06 |
| NN3015 | NN3015K | 75 | 115 | 30 | 1.11 |
| NN3016 | NN3016K | 80 | 125 | 34 | 1.54 |
| NN3017 | NN3017K | 85 | 130 | 34 | 1.63 |
| NN3018 | NN3018K | 90 | 140 | 37 | 2.09 |
| NN3019 | NN3019K | 95 | 145 | 37 | 2.19 |
| NN3020 | NN3020K | 100 | 150 | 37 | 2.28 |
| NN3021 | NN3021K | 105 | 160 | 41 | 2.88 |
| NN3022 | NN3022K | 110 | 170 | 45 | 3.71 |
| NN3024 | NN3024K | 120 | 180 | 46 | 4.04 |
| NN3026 | NN3026K | 130 | 220 | 52 | 5.88 |
| NN3028 | NN3028K | 140 | 210 | 53 | 6.34 |
| NN3030 | NN3030K | 150 | 225 | 56 | 7.77 |
| NN3032 | NN3032K | 160 | 240 | 60 | 9.41 |
| NN3034 | NN3034K | 170 | 260 | 67 | 12.8 |
| NN3036 | NN3036K | 180 | 280 | 74 | 16.8 |
| NN3038 | NN3038K | 190 | 290 | 75 | 17.8 |
| NN3040 | NN3040K | 200 | 310 | 82 | 22.7 |
| NN3044 | NN3044K | 220 | 340 | 90 | 29.6 |
| NN3048 | NN3048K | 240 | 360 | 92 | 32.7 |
| NN3052 | NN3052K | 260 | 400 | 104 | 47.7 |
| NN3056 | NN3056K | 280 | 420 | 106 | 51.1 |
| NN3060 | NN3060K | 300 | 460 | 118 | 70.7 |
| NN3064 | NN3064K | 320 | 480 | 121 | 76.6 |
Brass Cage NN3009KP4 Bearing Small Size for Machine Shaft , Get Cheap Price from China Roller Bearing Factory Now !
