Product Details
Place of Origin: CHINA
Brand Name: FSK / FAG / NTN / NSK / KOYO / ZWZ / HRB / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: 81109
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Let's Chat in Detail
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 7 Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/day
Model No.: |
81109 |
Size: |
45 × 65 × 14mm |
Weight: |
0.13kg |
Cage: |
Brass Cage / Steel Cage |
Part Name: |
China Cylindrical Roller Bearings |
Character: |
Plane Thrust |
Model No.: |
81109 |
Size: |
45 × 65 × 14mm |
Weight: |
0.13kg |
Cage: |
Brass Cage / Steel Cage |
Part Name: |
China Cylindrical Roller Bearings |
Character: |
Plane Thrust |
High Temperature 81109 Thrust Cylindrical Roller Bearings Single Row
Thrust Cylindrical Roller Bearings Description
Cylindrical roller thrust bearings can be used for bearing arrangements which are requied to carry very heavy axial loads, to be insensitive to shock loads, to be stiff and to take up little axial space.Their main use is in applications where the load carrying capacity of thrust ball bearings is inadequate.
Most cylindrical roller thrust bearings are single direction bearings.They can provide axial support for a shaft in one diection.They are particularly simple in design and are available as single row bearings or as multi-row bearings.
Bearing Specification :
|
Model Number |
81109 |
|
Part Name |
Thrust Cylindrical Roller Bearings |
|
Brand |
FSK / FAG / NTN / NSK / KOYO / ZWZ / HRB / OEM |
|
Precision Rating |
ABEC-1 to ABEC-9 |
| Vibration and Noise | Z0V0 / Z1V1 / Z2V2 / Z3V3 |
| Material | Gcr15 Chrome Steel |
| Number of Row | Single Row |
| Cage | Brass Cage / Steel Cage |
|
Dimensions(mm)(d*D*b) |
45 × 65 × 14mm |
|
Weight / Mass ( KG ) |
0.13kg |
|
HS Code |
8482500000 |
| Original Country Show | CHINA |
Bearing Drawing :
81109 Cylindrical Roller Thrust Bearing,Brass Cage / Steel cage ,Metric,45mm Bore,65mm OD,14mm Width
Bearings Detailed Pictures :
Part of Thrust Cylindrical Roller Bearings List:
| Size (mm) | Load Rating(KN) | Limit Speed(r/min) | Weight(kg) | Bearing No. | |||
| d | D | H | Ca | Coa | |||
| 15 | 28 | 9 | 14.4 | 28.5 | 11000 | 0.024 | 81102 |
| 17 | 30 | 9 | 15.9 | 33.5 | 10000 | 0.027 | 81103 |
| 20 | 35 | 10 | 24.9 | 53 | 8500 | 0.037 | 81104 |
| 25 | 42 | 11 | 33.5 | 76 | 7000 | 0.053 | 81105 |
| 30 | 47 | 11 | 35.5 | 86 | 6000 | 0.057 | 81106 |
| 52 | 16 | 64 | 141 | 6000 | 0.123 | 81206 | |
| 60 | 18 | 69 | 197 | 5000 | 0.24 | 89306 | |
| 35 | 52 | 12 | 39 | 101 | 5500 | 0.073 | 81107 |
| 62 | 18 | 80 | 199 | 4900 | 0.195 | 81207 | |
| 68 | 20 | 80 | 237 | 4600 | 0.34 | 89307 | |
| 40 | 60 | 13 | 56 | 148 | 4800 | 0.105 | 81108 |
| 68 | 19 | 107 | 265 | 4400 | 0.249 | 81208 | |
| 78 | 22 | 122 | 385 | 4000 | 0.484 | 89308 | |
| 90 | 23 | 135 | 480 | 3600 | 0.747 | 87409 | |
| 45 | 65 | 14 | 59 | 163 | 4400 | 0.13 | 81109 |
| 73 | 20 | 105 | 265 | 4000 | 0.287 | 81209 | |
| 85 | 24 | 139 | 445 | 3600 | 0.615 | 89309 | |
| 100 | 25 | 154 | 560 | 3200 | 1.054 | 87409 | |
| 50 | 70 | 14 | 61 | 177 | 4000 | 0.14 | 81110 |
| 78 | 22 | 117 | 315 | 3700 | 0.356 | 81210 | |
| 95 | 27 | 167 | 560 | 3200 | 0.887 | 89310 | |
| 110 | 27 | 200 | 740 | 2900 | 1.316 | 87410 | |
| 110 | 36 | 295 | 900 | 3000 | 1.316 | 89410 | |
| 110 | 31 | 295 | 900 | 3000 | 1.125 | 89410X | |
| 55 | 78 | 16 | 90 | 300 | 3600 | 0.218 | 81111 |
| 90 | 25 | 154 | 405 | 3300 | 0.568 | 81211 | |
| 105 | 30 | 184 | 600 | 2900 | 1.18 | 89311 | |
| 120 | 29 | 222 | 870 | 2600 | 1.698 | 87411 | |
| 60 | 85 | 17 | 103 | 315 | 3300 | 0.266 | 81112 |
| 95 | 26 | 172 | 480 | 3100 | 0.642 | 87212 | |
| 110 | 30 | 196 | 670 | 2700 | 1.26 | 89312 | |
| 130 | 32 | 260 | 1000 | 2500 | 2.26 | 87412 | |
| 130 | 42 | 390 | 1220 | 2500 | 2.818 | 89412 | |
| 65 | 90 | 18 | 107 | 340 | 3100 | 0.31 | 81113 |
| 100 | 27 | 177 | 500 | 2900 | 0.721 | 81213 | |
| 115 | 30 | 194 | 670 | 2600 | 1.33 | 89313 | |
| 140 | 45 | 445 | 1410 | 2300 | 3.52 | 89413 | |
Our Bearing Production Range:
| Roller Bearings | Truck Wheel Bearing |
| Automotive Hub Bearing | |
| Concret Mixer Bearing | |
| Tapered Roller Bearings | |
| Cylindrical Roller Bearings | |
| Spherical Roller Bearings | |
| Needle Roller Bearings | |
| Thrust Roller Bearings | |
| Ball Bearings | Deep Groove Ball Bearings |
| Angular Contact Ball Bearings | |
| Self-aligning Ball Bearings | |
| Thrust Ball Bearings | |
| Angular Contact Ball Bearings | |
| Other Bearings | Clutch Release Bearing |
| Pillow Block Bearing | |
| Insert Bearings | |
| Joint Bearings | |
| Linear Bearings |
FSK Bearing Packings
1. Industrial packing: plastic bag + kraft paper + carton+ plywood pallets
2. Commerical packing:1pc/plastic bag + box + carton + plywood pallets
3. As the customer's requirment
High Temperature 81109 Thrust Cylindrical Roller Bearings Single Row , Get Cheap Price from China Roller Bearing Factory Now !
