Product Details
Place of Origin: CHINA
Brand Name: INA / FAG / TIMKE / NTN / NSK / KOYO / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: ZARF40115LTN
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Let's Chat in Detail
Packaging Details: 1.Industrial packaging: plastic bag + kraft paper + carton + plywood pallets; plastic tube + carton + plywood pallets; 2. Commercial packing: 1pc/plastic bag + color box + carton + plywood pallets 3. As the clients' requirement
Delivery Time: 3 Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/day
Model No.: |
ZARF40115LTN |
Size: |
40 × 115 × 93mm |
Weight: |
3kg |
Cage: |
Brass Cage / Steel Cage |
Advantage: |
Low Vocie,high Speed, Long Life |
Character: |
Combined |
Model No.: |
ZARF40115LTN |
Size: |
40 × 115 × 93mm |
Weight: |
3kg |
Cage: |
Brass Cage / Steel Cage |
Advantage: |
Low Vocie,high Speed, Long Life |
Character: |
Combined |
Endurable Combined Needle Roller Thrust Bearings 40mm ID 115mm OD
Bearing Specification :
|
Model Number |
ZARF40115LTN |
|
Part Name |
Needle Roller Bearing |
|
Brand |
INA / FAG / TIMKE / NTN / NSK / KOYO / OEM |
|
Precision Rating |
ABEC-1 to ABEC-9 |
| Vibration and Noise | Z0V0 / Z1V1 / Z2V2 / Z3V3 |
| Material | Gcr15 Chrome Steel |
| Number of Row | Single Row |
| Cage | Brass Cage / Steel Cage |
|
Dimensions(mm)(d*D*b) |
40 × 115 × 93mm |
|
Weight / Mass ( KG ) |
3kg |
|
HS Code |
8482800000 |
| Original Country Show | CHINA |
ZARF40115LTN Bearing Drawing Picture
Bearings Detailed Pictures :
Same Series Bearing We Do
| Part NO. | Weight/g | Part NO. | Weight/g | Dimensions/mm | |||
| d | D | H | C | ||||
| ZARF 1560TN | 420 | ZARF 1560LTN | 450 | 15 | 60 | 40 | 14 |
| ZARF 1762TN | 490 | ZARF 1762LTN | 520 | 17 | 62 | 43 | 14 |
| ZARF 2068TN | 560 | ZARF 2068LTN | 610 | 20 | 68 | 46 | 14 |
| ZARF 2080TN | 1100 | ZARF 2080LTN | 1220 | 20 | 80 | 60 | 18 |
| ZARF 2575TN | 780 | ZARF 2575LTN | 840 | 25 | 75 | 50 | 18 |
| ZARF 2590TN | 1600 | ZARF 2590LTN | 1750 | 25 | 90 | 60 | 18 |
| ZARF 3080TN | 850 | ZARF 3080LTN | 900 | 30 | 80 | 50 | 18 |
| ZARF 30105TN | 1950 | ZARF 30105LTN | 2150 | 30 | 105 | 66 | 18 |
| ZARF 3590TN | 1120 | ZARF 3590LTN | 1250 | 35 | 90 | 54 | 18 |
| ZARF 35110TN | 1600 | ZARF 35110LTN | 1850 | 35 | 110 | 66 | 18 |
| ZARF 40100TN | 1350 | ZARF 40100LTN | 1450 | 40 | 100 | 54 | 18 |
| ZARF 40115TN | 2700 | ZARF 40115LTN | 3000 | 40 | 115 | 75 | 22.5 |
| ZARF 45105TN | 1700 | ZARF 45105LTN | 1850 | 45 | 105 | 60 | 22.5 |
| ZARF 45130TN | 3900 | ZARF 45130LTN | 4300 | 45 | 130 | 82 | 22.5 |
| ZARF 50115TN | 2100 | ZARF 50115LTN | 2450 | 50 | 115 | 60 | 22.5 |
| ZARF 50140TN | 4200 | ZARF 50140LTN | 4650 | 50 | 140 | 82 | 22.5 |
| ZARF 55145TN | 4500 | ZARF 55145LTN | 5000 | 55 | 145 | 82 | 22.5 |
| ZARF 60150TN | 4700 | ZARF 60150LTN | 5350 | 60 | 150 | 82 | 22.5 |
| ZARF 65155TN | 5120 | ZARF 65155LTN | 5720 | 65 | 155 | 82 | 22.5 |
| ZARF 70160TN | 5200 | ZARF 70160LTN | 6000 | 70 | 160 | 82 | 22.5 |
| ZARF 75185TN | 9400 | ZARF 75185LTN | 10610 | 75 | 185 | 100 | 27 |
| ZARF 90210TN | 13700 | ZARF 90210LTN | 15100 | 90 | 210 | 110 | 32 |
The Other Bearings We Do
| Ball Bearing | Deep Groove Ball Bearing | 60 **,618 ** (1008), 619**(1009),62 **, 63 **, 64 **, |
| 160 **(70001 ) | ||
| Thrust Ball Bearing | 511 ** (81) ,512 **(82) ,513 (83) ,514 ** (84) series and Angular Contact Thrust all Bearings like: 5617 ** (1687) ,5691 ** (91681), 5692 ** (91682) series | |
| Angular Contact Ball bearing | SN718 **(11068 ) ,70 ** 72 **,73 **, and B (66), C (36), AC (46) series ; otherwise include QJ and QJF series | |
| Roller Bearing | Spherical Roller bearing | 239**, 230**,240**, 231**, 241**, 222**, 232**, 223**, 233**, 213**, 238**, 248**, 249**and special series include 26** i.e 2638 (3738), 2644 (3844) and so on |
| Taper Roller Bearing | 329**(20079),210**(71), 320**(20071),302**(72), 322**(75), 303**(73), 313**(273),323**(76), 3519**(10979), 3529**(20979),3510**(971), 3520**(20971),3511**(10977), 3521**(20977), 3522**(975), 319**(10076),3819**(10779),3829**(20779), 3810**(777,771), 3820**(20771), 3811**(10777,777) for example: 77752, 77788, 77779 and also include Inch series bearings suchas 938/932 single and double row i.e M255410CD etc. | |
| Thrust Roller Bearing | 292**(90392), 293**(90393),294**(90394),994**(90194), and 9069 series. | |
| Cylindrical Roller Bearing | NU10**, NU2**,NU22**, NU3**,NU23**, NU4**, N, NJ ,NUP series as well as NB, NN, NNU series of big bearings, and we also have Split Bearings 412740, 422740 used in cement industry.And FC, FCD series used in Steel Industry. |
