Product Details
Place of Origin: CHINA
Brand Name: FSK / IKO / THK / NSK / FAG / NTN / KOYO
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: LM50UU AJ
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Part Name: |
Linear Motion Bearing |
Size: |
50mm × 80mm × 100mm |
Weight: |
1.58KG |
Type: |
Adjustable Type |
Cage: |
Steel Cage / Nylon Cage / Light Alloy Cage |
Sample: |
Free Sample Available |
Part Name: |
Linear Motion Bearing |
Size: |
50mm × 80mm × 100mm |
Weight: |
1.58KG |
Type: |
Adjustable Type |
Cage: |
Steel Cage / Nylon Cage / Light Alloy Cage |
Sample: |
Free Sample Available |
LM50UU AJ Linear Motion Bearings , Metal / Plastic Linear Bearing
Bearing Specification :
|
FSK Bearing Model Number |
LM50UU AJ |
|
Part Name |
Linear Motion Bearing |
| Structure | Linear Ball Bearings |
|
Brand |
FSK / IKO / THK / NSK / FAG / NTN / KOYO |
|
Ball Circuit |
Six Row |
|
Material |
Gcr15 Chrome Steel |
|
Precision Rating |
ABEC-1 to ABEC-9 P0 / P6 / P5 / P4 /P2 |
| Vibration and Noise | Z0V0 / Z1V1 / Z2V2 / Z3V3 |
| Cage | Steel Cage / Nylon Cage / Light Alloy Cage |
| Type | Adjustable Type |
| Package | Single Carton Box / Pallet / Wooden case |
| Weight | 1.58kg |
| Dimension | 50mm × 80mm × 100mm |
| HS Code | 8482800000 |
| Original Country Show | CHINA |
Description:
LM - UU series
LM - UU OP series
LM - LUU series
LME - UU series
LMF - UU series
LMK - UU series
LMH - UU series
LMF - LUU series
LMK - UU series
LMH - LUU series
SCS - UU series
SCS - LUU series
SBR - UU series
TBR - UU series
SK (SHA) series
SHF series
Inside diameter: 6 , 8 , 10 , 12 , 13 , 16 , 20 , 25 , 30 , 35 , 40 , 50 , 60.
Other Models We Can Offer
| LM-UU | Ball circuit | Weight(g) | LM-UU-AJ | Ball circuit | LM-UU-OP | Ball circuit | Weight(g) |
| LM3 | 4 | 1.35 | --------- | ---- | --------- | --------- | --------- |
| LM4 | 4 | 1.9 | --------- | ---- | --------- | --------- | --------- |
| LM5UU | 4 | 4 | ---------- | ---- | ---------- | ---------- | ---------- |
| LM6UU | 4 | 7.6 | LM6UU-AJ | 4 | --------- | --------- | --------- |
| LM8SUU | 4 | 10.4 | LM8SUU-AJ | 4 | --------- | --------- | --------- |
| LM8UU | 4 | 15 | LM8UU-AJ | 4 | ---------- | ---------- | ---------- |
| LM10UU | 4 | 29.5 | LM10UU-AJ | 4 | LM10UU-OP | 3 | 23 |
| LM12UU | 4 | 31.5 | LM12UU-AJ | 4 | LM12UU-OP | 3 | 25 |
| LM13UU | 4 | 43 | LM13UU-AJ | 4 | LM13UU-OP | 3 | 34 |
| LM16UU | 5 | 69 | LM16UU-AJ | 5 | LM16UU-OP | 4 | 52 |
| LM20UU | 5 | 87 | LM20UU-AJ | 5 | LM20UU-OP | 4 | 69 |
| LM25UU | 6 | 220 | LM25UU-AJ | 6 | LM25UU-OP | 5 | 188 |
| LM30UU | 6 | 250 | LM30UU-AJ | 6 | LM30UU-OP | 5 | 210 |
| LM35UU | 6 | 390 | LM35UU-AJ | 6 | LM35UU-OP | 5 | 335 |
| LM40UU | 6 | 585 | LM40UU-AJ | 6 | LM40UU-OP | 5 | 500 |
| LM50UU | 6 | 1580 | LM50UU-AJ | 6 | LM50UU-OP | 5 | 1340 |
| LM60UU | 6 | 1860 | LM60UU-AJ | 6 | LM60UU-OP | 5 | 1610 |
| LM80UU | 6 | 4420 | LM80UU-AJ | 6 | LM80UU-OP | 5 | 3650 |
| LM100UU | 6 | 8600 | LM100UU-AJ | 6 | LM100UU-OP | 5 | 7200 |
| LM120UU | 8 | 15000 | LM120UU-AJ | 8 | LM120UU-OP | 6 | 11600 |
| LM150UU | 8 | 20250 | LM150UU-AJ | 8 | LM150UU-OP | 6 | 15700 |
Bearings Detailed Pictures :
LM50UU AJ Linear Motion Bearings Metal Linear Bearing and Plastic Linear Bearing, Get Cheap Price from China Steering Bearing Factory Now !
