Product Details
Place of Origin: CHINA
Brand Name: FSK / IKO / THK / NSK / KOYO / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: LM16UU OP
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Retainer: |
Steel / Resin / Stainless |
Weight: |
0.069kg |
ID: |
16mm |
OD: |
28mm |
Length: |
37mm |
Tolerance: |
ABEC1 ABEC3 ABEC5 ABEC7 |
Retainer: |
Steel / Resin / Stainless |
Weight: |
0.069kg |
ID: |
16mm |
OD: |
28mm |
Length: |
37mm |
Tolerance: |
ABEC1 ABEC3 ABEC5 ABEC7 |
LM16UU OP Linear Motion Bearings 13mm × 23mm × 32mm Standard Linear Slide
Bearing Specification :
|
FSK Bearing Model Number |
LM16UU OP |
|
Part Name |
Linear Motion Bearing |
| Structure | Linear Ball Bearings |
|
Brand |
FSK / IKO / THK / NSK / KOYO / OEM |
|
Number of Row |
Four Row |
|
Material |
Gcr15 Chrome Steel |
|
Precision Rating |
ABEC-1 to ABEC-9 |
| Vibration and Noise | Z0V0 / Z1V1 / Z2V2 / Z3V3 |
| Cage | Steel Cage / Nylon Cage / Light Alloy Cage |
| Seal Type | Open / Standard / Adjustable Clearance |
| Package | Single Carton Box / Pallet / Wooden case |
| Weight | 0.069kg |
| Dimension | 16mm × 28mm × 37mm |
| HS Code | 8482990000 |
| Original Country Show | CHINA |
Description:
Other Models We Can Offer
| Designation | Major dimensions(mm) | Ratings load | |||||
| LM-OP | Number of ball rows | dr | D | L | Dynamic CN | Static CoN | |
| Weight | |||||||
| (g) | |||||||
| LM10-OP | 4 | 30 | 10 | 19 | 29 | 372 | 549 |
| LM12-OP | 5 | 31.5 | 12 | 21 | 30 | 510 | 784 |
| LM13-OP | 5 | 43 | 13 | 23 | 32 | 510 | 784 |
| LM16-OP | 5 | 69 | 16 | 28 | 37 | 774 | 1180 |
| LM20-OP | 6 | 87 | 20 | 32 | 42 | 882 | 1370 |
| LM25-OP | 6 | 220 | 25 | 40 | 59 | 980 | 1570 |
| LM30-OP | 6 | 250 | 30 | 45 | 64 | 1570 | 2740 |
| LM35-OP | 6 | 390 | 35 | 52 | 70 | 1670 | 3140 |
| LM40-OP | 6 | 585 | 40 | 60 | 80 | 2160 | 4020 |
| LM50-OP | 6 | 1580 | 50 | 80 | 100 | 3820 | 7940 |
| LM60-OP | 6 | 2000 | 60 | 90 | 110 | 4700 | 10000 |
| LM80-OP | 6 | 4420 | 80 | 120 | 140 | 7350 | 16000 |
| LM100-OP | 6 | 8600 | 100 | 150 | 175 | 14120 | 34800 |
| LM120-OP | 8 | 14900 | 120 | 180 | 200 | 16400 | 40000 |
| LM150-OP | 8 | 20150 | 150 | 210 | 240 | 21100 | 54300 |
Bearings Detailed Pictures :
Advantage :
1. Low friction
2. Wear resistant
3. Easy replacement
4. Minimum lubrication
5. Requires little attention
6. Running in not required
7. Dimensions relatively small
8. No scraping required tofit shaft
Our Service :
1. Highest quality and most competitive price----we are the only one manufacture who adopts import raw materials. Low bad rates, is just 0.1%. It is amazing, and with cheap price and guaranteed quality.
2. Delivery fast -----Goods be sent out within 3 to 7 days based on order quantity.
3. Professional-----We are special in source and sells, as development, methods, conjugations, and handling.
4. Best service-----Answering e-mails or solving questions timely. Delivery and update information on time. Trust, good quality and service are the basic of long term business.
LM16UU OP Linear Motion Bearings 13mm × 23mm × 32mm Standard Linear Slide, Get Cheap Price from China Steering Bearing Factory Now !
