Wuxi FSK Transmission Bearing Co., Ltd fskbearing@hotmail.com 86-510-82713083
Product Details
Place of Origin: CHINA
Brand Name: THK / IKO / NSK / TIMKEN / FAG / NTN / KOYO / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: LM13 UU
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Material: |
Gcr15 Chrome Steel |
Dimension: |
13mm × 23mm × 32mm |
Number Of Row: |
Four Row |
Part Name: |
Linear Motion Bearing |
Model: |
LM13 UU |
Cage: |
Steel Cage / Nylon Cage / Light Alloy Cage |
Material: |
Gcr15 Chrome Steel |
Dimension: |
13mm × 23mm × 32mm |
Number Of Row: |
Four Row |
Part Name: |
Linear Motion Bearing |
Model: |
LM13 UU |
Cage: |
Steel Cage / Nylon Cage / Light Alloy Cage |
LM13 UU Linear Motion Bearings Small Size Z0V0 / Z1V1 / Z2V2 / Z3V3
Bearing Specification :
|
FSK Bearing Model Number |
LM13 UU |
|
Part Name |
Linear Motion Bearing |
| Structure | Linear Ball Bearings |
|
Brand |
THK / IKO / NSK / TIMKEN / FAG / NTN / KOYO / OEM |
|
Number of Row |
Four Row |
|
Material |
Gcr15 Chrome Steel |
|
Precision Rating |
P0 P6 P5 P4 P2 |
| Vibration and Noise | Z0V0 / Z1V1 / Z2V2 / Z3V3 |
| Cage | Steel Cage / Nylon Cage / Light Alloy Cage |
| Dimension | 13mm × 23mm × 32mm |
| HS Code | 8482800000 |
| Original Country Show | CHINA |
Description:
Other Models We Can Offer
| Model No. | Main dimensions | Basic load rating | ||||
| Inscribed bore diameter | Outer diameter | Length | Dynamic rating | Static rating | Mass | |
| dr | D | L | C | C0 | ||
| mm | mm | mm | N | N | G | |
| LM 3 | 3 | 7 | 10 | 88.2 | 108 | 1.4 |
| LM 4 | 4 | 8 | 12 | 88.2 | 127 | 1.9 |
| LM 5 | 5 | 10 | 15 | 167 | 206 | 4 |
| LM 6 | 6 | 12 | 19 | 206 | 265 | 8 |
| LM 8S | 8 | 15 | 17 | 176 | 225 | 11 |
| LM 8 | 8 | 15 | 24 | 265 | 402 | 16 |
| LM 10 | 10 | 19 | 29 | 373 | 549 | 30 |
| LM 12 | 12 | 21 | 30 | 412 | 598 | 31.5 |
| LM 13 | 13 | 23 | 32 | 510 | 775 | 43 |
| LM 16 | 16 | 28 | 37 | 775 | 1180 | 69 |
| LM 20 | 20 | 32 | 42 | 863 | 1370 | 87 |
| LM 25 | 25 | 40 | 59 | 980 | 1570 | 220 |
| LM 30 | 30 | 45 | 64 | 1570 | 2750 | 250 |
| LM 35 | 35 | 52 | 70 | 1670 | 3140 | 390 |
| LM 40 | 40 | 60 | 80 | 2160 | 4020 | 585 |
| LM 50 | 50 | 80 | 100 | 3820 | 7940 | 1580 |
Bearings Detailed Pictures :
Advantage :
1. Low friction
2. Wear resistant
3. Easy replacement
4. Minimum lubrication
5. Requires little attention
6. Running in not required
7. Dimensions relatively small
8. No scraping required tofit shaft
Our Service :
1. Highest quality and most competitive price----we are the only one manufacture who adopts import raw materials. Low bad rates, is just 0.1%. It is amazing, and with cheap price and guaranteed quality.
2. Delivery fast -----Goods be sent out within 3 to 7 days based on order quantity.
3. Professional-----We are special in source and sells, as development, methods, conjugations, and handling.
4. Best service-----Answering e-mails or solving questions timely. Delivery and update information on time. Trust, good quality and service are the basic of long term business.
LM13 UU Linear Motion Bearings Small Size LM10 UU LM12 UU LM16 UU, Get Cheap Price from China Steering Bearing Factory Now !
