Product Details
Place of Origin: JAPAN
Brand Name: NSK / NTN / FAG / NACHI / KOYO / FSK / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: 6834
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Model No.: |
6834 |
Size: |
170 × 215 × 22mm |
Weight: |
1.85kg |
Seal: |
2RS |
Part Name: |
China Deep Groove Ball Bearing |
Character: |
Thin Wall |
Model No.: |
6834 |
Size: |
170 × 215 × 22mm |
Weight: |
1.85kg |
Seal: |
2RS |
Part Name: |
China Deep Groove Ball Bearing |
Character: |
Thin Wall |
Radial Load 6834 Thin Ball Bearing with Rubble Seal Single Row
Bearing Specification :
Bearing Model No.
6834
Bearing Name:
Deep Groove Ball Bearing
Bearing Size:
170 × 215 × 22mm
Bearing Weight:
1.85kg
Seal:
Rubble Seal
Bearing Drawing :
Bearings Detailed Pictures :
Thin-Wall Deep Groove Ball Bearing List:
| Bearing No. | Size(mm) | Seal Type | Mass(kg) | |||||
| Open | Steel Shield | |||||||
| d | D | B | r | |||||
| (min) | ||||||||
| 6828 | 140 | 175 | 18 | 1.1 | 6828 | - | - | 0.84 |
| 6928 | 140 | 190 | 24 | 1.5 | 6928 | - | - | 1.9 |
| 16028 | 140 | 210 | 22 | 1.1 | 16028 | - | - | 2.86 |
| 6028 | 140 | 210 | 33 | 2 | 6028 | 6028Z | 6028ZZ | 4.15 |
| 6228 | 140 | 250 | 42 | 3 | 6228 | 6228Z | 6228ZZ | 7.47 |
| 6328 | 140 | 300 | 62 | 4 | 6328 | 6328Z | 6328ZZ | 21.8 |
| 6830 | 150 | 190 | 20 | 1.1 | 6830 | - | - | 1.2 |
| 6930 | 150 | 210 | 28 | 2 | 6930 | - | - | 2.64 |
| 16030 | 150 | 225 | 24 | 1.1 | 16030 | - | - | 3.58 |
| 6030 | 150 | 225 | 35 | 2.1 | 6030 | 6030Z | 6030ZZ | 4.48 |
| 6230 | 150 | 270 | 45 | 3 | 6230 | 6230Z | 6230ZZ | 9.41 |
| 6330 | 150 | 320 | 65 | 4 | 6330 | - | - | 26.2 |
| 6832 | 160 | 200 | 20 | 1.1 | 6832 | - | - | 1.3 |
| 6932 | 160 | 220 | 28 | 2 | 6932 | - | - | 3.01 |
| 6032 | 160 | 240 | 38 | 2.1 | 6032 | - | - | 5.89 |
| 6232 | 160 | 290 | 48 | 3 | 6232 | 6232Z | 6232ZZ | 14.3 |
| 6332 | 160 | 340 | 68 | 4 | 6332 | - | - | 28.6 |
| 6834 | 170 | 215 | 22 | 1.1 | 6834 | - | - | 1.85 |
| 6934 | 170 | 230 | 28 | 2 | 6934 | - | - | 3.17 |
| 6034 | 170 | 260 | 42 | 2.1 | 6034 | - | - | 7.92 |
| 6234 | 170 | 310 | 52 | 4 | 6234 | - | - | 17.5 |
| 6334 | 170 | 360 | 72 | 4 | 6334 | - | - | 34 |
| 6836 | 180 | 225 | 22 | 1.1 | 6836 | - | - | 2.02 |
| 6936 | 180 | 250 | 33 | 2 | 6936 | - | - | 4.68 |
| 6036 | 180 | 280 | 46 | 2.1 | 6036 | - | - | 10.3 |
| 6236 | 180 | 320 | 52 | 4 | 6236 | - | - | 18.3 |
| 6336 | 180 | 380 | 75 | 4 | 6336 | - | - | 41.9 |
| 6838 | 190 | 240 | 24 | 1.5 | 6838 | - | - | 2.6 |
| 6938 | 190 | 260 | 33 | 2 | 6938 | - | - | 4.9 |
| 6038 | 190 | 290 | 46 | 2.1 | 6038 | - | - | 10.8 |
| 6238 | 190 | 340 | 55 | 4 | 6238 | - | - | 23 |
| 6338 | 190 | 400 | 78 | 5 | 6338 | - | - | 48.2 |
| 6840 | 200 | 250 | 24 | 1.5 | 6840 | - | - | 2.7 |
Our Deep Groove Ball Bearings:
Deep groove ball bearings 6834
miniature thin-wall bearings,and different types of low noise,non-standard and special bearings.
(1) bearing bore diameter:3mm-50mm
(2) Bearing range:
60series bearing:606,607.608,6000,6001,6002,6003,6004,6005,6006,6007,6008,6009, 6010,6012,6013,6014,6015
62series bearing :626,627,628,629,6200,6201,6202,6203,6204,6205,6206,6207,6208,6209,6210,
6211,6212
63series bearing:6300,6301,6302,6303,6304,6305,6306,6307,6308,6309,6310,6311,6312 67series bearing:6705
68series bearing:686,687,688,689,6800,6801,6802,6803,6804,6805,6806,6807,6808,6809,6810 69series bearing:696,697,698,699,6900,6901,6902,6903,6904,6905,6906,6907,6908,6909,6910 16000series bearing:16001,16002,16003,16005,16007
(3) bearing Sealing form:OPEN,RS,2RS,Z,ZZ,RZ,2RZ,N,NR
(4) bearing Material:Gcr15
(5) Quality standard: ISO9001:2000
(6) Chief uses:automatic transmission mechanisms, home appliance motors, motorcycles, power tools, sports goods, office applianceal
Our Bearing Production Range:
1. Tapered Roller Bearing
2. Deep Groove Ball Bearing
3. Truck Wheel Bearing
4. Automobile Wheel Bearing
5. Cement Mixer Bearing
6. Clutch Release Bearing
7. Self Aligning Ball Bearing
8. Cylindrical Roller Bearing
9. Needle Bearing
10. Angular Contact Bearing
11. Thrust Ball Bearing
12. Thrust Roller Bearing
13. Pillow Block Bearing
14. Spherical Roller Bearing
