Product Details
Place of Origin: CHINA
Brand Name: FSKG / KBE / FAG / NTN / NSK / KOYO / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: 61944MA/C3
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Let's Chat in Detail
Packaging Details: 1.Industrial packaging: plastic bag + kraft paper + carton + plywood pallets; plastic tube + carton + plywood pallets; 2. Commercial packing: 1pc/plastic bag + color box + carton + plywood pallets 3. As the clients' requirement
Delivery Time: 3 Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/day
Model No.: |
61944MA/C3 |
Size: |
220 × 300 × 38 Mm |
Weight: |
9.4kg |
Cage: |
Steel Cage / Iron Caage |
Advantage: |
Low Vocie,high Speed, Long Life |
Character: |
63007-2RSR/C3 Bearing / 63007 2RSRC3 Bearing / 63007 2RSR C3 Bearing |
Model No.: |
61944MA/C3 |
Size: |
220 × 300 × 38 Mm |
Weight: |
9.4kg |
Cage: |
Steel Cage / Iron Caage |
Advantage: |
Low Vocie,high Speed, Long Life |
Character: |
63007-2RSR/C3 Bearing / 63007 2RSRC3 Bearing / 63007 2RSR C3 Bearing |
Thin Wall 61944MA/C3 Deep Groove Ball Bearing Large Turntable Slewing Bearing for Rolling Mill
61944MA/C3 Bearing Specification :
Model Number |
61944MA/C3 |
Part Name |
Deep Groove Ball Bearing |
Application | Rolling Mill Bearing |
Brand |
FSKG / KBE / FAG / NTN / NSK / KOYO / OEM |
Precision Rating |
ABEC-5 / ABEC-7 |
Material | Gcr15 Chrome Steel |
Number of Row | Single Row |
Dimensions(mm)(d*D*b) |
220 × 300 × 38 mm |
Weight / Mass ( KG ) |
9.4kg |
HS Code |
8482800000 |
Original Country Show | CHINA |
61944MA/C3 Bearings Detailed Pictures :
The Other Bearing We Offer
Designation | Principal dimensions | Basic load ratings | Fatigue load limit | Speed ratings | ||||
d | D | B | dynamic | static | Pu | Reference speed | Limiting speed | |
C | C0 | |||||||
mm | KN | KN | r/min | |||||
61922 MA | 110 | 150 | 20 | 43.6 | 45 | 1.66 | 9000 | 7500 |
61924 MA | 120 | 165 | 22 | 55.3 | 57 | 2.04 | 8000 | 6700 |
6024 MA | 120 | 180 | 28 | 88.4 | 80 | 2.75 | 7500 | 6300 |
6228 MA | 140 | 250 | 42 | 165 | 150 | 4.55 | 5300 | 4800 |
61928 MA | 140 | 190 | 24 | 66.3 | 72 | 2.36 | 7000 | 5600 |
61830 MA | 150 | 190 | 20 | 48.8 | 61 | 1.96 | 6700 | 4300 |
61930 MA | 150 | 210 | 28 | 88.4 | 93 | 2.9 | 6300 | 5300 |
61932 MA | 160 | 220 | 28 | 92.3 | 98 | 3.05 | 6000 | 5000 |
61934 MA | 170 | 230 | 28 | 93.6 | 106 | 3.15 | 5600 | 4800 |
61936 MA | 180 | 250 | 33 | 119 | 134 | 3.9 | 5300 | 4300 |
61938 MA | 190 | 260 | 33 | 117 | 134 | 3.8 | 5000 | 4300 |
61940 MA | 200 | 280 | 38 | 148 | 166 | 4.55 | 4800 | 3800 |
61944 MA | 220 | 300 | 38 | 151 | 180 | 4.75 | 4300 | 3600 |
16048 MA | 240 | 360 | 37 | 203 | 255 | 6.3 | 3600 | 3000 |
61948 MA | 240 | 320 | 38 | 159 | 200 | 5.1 | 4000 | 3200 |
16052 MA | 260 | 400 | 44 | 238 | 310 | 7.2 | 3200 | 2800 |
61952 MA | 260 | 360 | 46 | 212 | 270 | 6.55 | 3600 | 3000 |
61856 MA | 280 | 350 | 33 | 138 | 200 | 4.75 | 3400 | 2800 |
61956 MA | 280 | 380 | 46 | 216 | 285 | 6.7 | 3200 | 2800 |
16056 MA | 280 | 420 | 44 | 242 | 335 | 7.5 | 3000 | 2600 |
16060 MA | 300 | 460 | 50 | 286 | 405 | 8.8 | 2800 | 1800 |
61860 MA | 300 | 380 | 38 | 172 | 245 | 5.6 | 3200 | 2600 |
61960 MA | 300 | 420 | 56 | 270 | 375 | 8.3 | 3000 | 2400 |
61864 MA | 320 | 400 | 38 | 172 | 255 | 5.7 | 3000 | 2400 |
60964 MA | 320 | 440 | 37 | 216 | 310 | 6.7 | 2800 | 2400 |
61964 MA | 320 | 440 | 56 | 276 | 400 | 8.65 | 2800 | 2400 |
16064 MA | 320 | 480 | 50 | 281 | 405 | 8.65 | 2600 | 2200 |
6264 MA | 320 | 580 | 92 | 527 | 800 | 16 | 2200 | 1900 |
6268 MA | 340 | 620 | 92 | 559 | 900 | 17.3 | 2000 | 1800 |
61968 MA | 340 | 460 | 56 | 281 | 425 | 9 | 2600 | 2200 |
16068 MA | 340 | 520 | 57 | 345 | 520 | 10.6 | 2400 | 2000 |
61868 MA | 340 | 420 | 38 | 178 | 275 | 6 | 2800 | 2400 |
61972 MA | 360 | 480 | 56 | 291 | 450 | 9.15 | 2600 | 2200 |
16072 MA | 360 | 540 | 57 | 351 | 550 | 11 | 1800 | 1400 |
60872 MA | 360 | 440 | 25 | 121 | 212 | 4.5 | 2600 | 2200 |
61872 MA | 360 | 440 | 38 | 182 | 285 | 6.1 | 2600 | 2200 |
61876 MA | 380 | 480 | 46 | 242 | 390 | 8 | 2400 | 2000 |
16076 MA | 380 | 560 | 57 | 377 | 620 | 12.2 | 2200 | 1400 |
61976 MA | 380 | 520 | 65 | 338 | 540 | 10.8 | 2400 | 1900 |
60880 MA | 400 | 500 | 31 | 163 | 280 | 5.6 | 2400 | 1900 |
61980 MA | 400 | 540 | 65 | 345 | 570 | 11.2 | 2200 | 1800 |
61880 MA | 400 | 500 | 46 | 247 | 405 | 8.15 | 2400 | 1900 |
61884 MA | 420 | 520 | 46 | 251 | 425 | 8.3 | 2200 | 1800 |
61984 MA | 420 | 560 | 65 | 351 | 600 | 11.4 | 2200 | 1800 |
61888 MA | 440 | 540 | 46 | 255 | 440 | 8.5 | 2200 | 1800 |
61988 MA | 440 | 600 | 74 | 410 | 720 | 13.2 | 2000 | 1600 |
Our Interntional Market:
Advantage :
1. Low friction
2. Wear resistant
3. Easy replacement
4. Minimum lubrication
5. Requires little attention
6. Running in not required
7. Dimensions relatively small
8. No scraping required tofit shaft
Our Service :
1. Highest quality and most competitive price----we are the only one manufacture who adopts import raw materials. Low bad rates, is just 0.1%. It is amazing, and with cheap price and guaranteed quality.
2. Delivery fast -----Goods be sent out within 3 to 7 days based on order quantity.
3. Professional-----We are special in source and sells, as development, methods, conjugations, and handling.
4. Best service-----Answering e-mails or solving questions timely. Delivery and update information on time. Trust, good quality and service are the basic of long term business.
About Us:
1.Direct China factory/Manufactur with strong Capability
We are direct bearing factory on Jiangsu, China for more than 10 years.300 bearing types,15 million sets items ar produced yearly and the output value more than 15 million US dollars last year.
We could complete all ordere items excellently with over one hundred of advanced equipments running in 6 plants in China.
2.Large ready stock&Fast Delivery Time
Rich in stock throughout the year for general bearing types,sush as Deep groove ball bearing,Tapered Roller Bearing,Thrust Ball Bearing,etc.
Based on above advantages,we delivery goods timely&fastly as your requests.Warehouse items would deliveried within 1-2 days.
By courier/air or by cargo/sea
3.Competitive price
Large stock and strong Capability enables us to offer more reasonable price all over the world. Customers could receive good quality bearings with attrative price at the same time from us.
4.Non-standard Customized Service
We could customize many non-standard bearings and workpiece as your drawing requests and offer in-house test report by professional engineers.All customized goods are made to order as requests.
5.Perfect Quality Control System
We have perfect quality control systems and testing equipments and experienced engineers for more than 10 years.We test bearings one by one assuring all bearings with high proformance.
6.Best After-sale service
Experienced different after-sale workers are online for more than 12hours a day, 7 days a week offering you different bearing solutions for you.
We are glad to receive any comments from all the world by email,by call/message or by Skype/wechat/whatsapp/Viber/QQ..etc.
8. Multi-language communications
FAQ
![]() |
|
Q:Are you a trader or manufacturer? | |
A:We are factory specializing in all kind of bearings. We can give you the best price and better service. | |
Q:What is your delivery time? | |
A:Sample order: Immediate delivery , bulk order: usually 30 days. | |
Q:Can i request sample? | |
A:Of course , sample is ok and we can give you a sample by free. | |
Q:What's the shipping way? | |
A:According to YOUR demands. | |
Q:Can you accept OEM or ODM? | |
A:Yes, of course. logo is also acceptable. | |
Q:How is quality controlled? | |
A:Quality is the key ! | |
Our QC team and engineer team works through all the process from an order placed to shipped. | |
Q: Can I come for a visit? | |
You are welcome to visit our factories , office and showroom ! Please contact our reception and we will help you to make a schedule. |
