Product Details
Place of Origin: CHINA
Brand Name: HIWIN / FSKG / KBE / OEM / Any Brand
Certification: ISO9001-2000 / CE / ROHS / UL / SGS
Model Number: EGW15SA
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Model No.: |
EGW15SA |
Size: |
41mm X 52mm X 5.5mm |
Weight: |
0.12kg |
Quality: |
ABEC-5 / ABEC-7 |
Stock: |
100pcs In Stock |
Origin: |
Wuxi Jiangsu |
Application: |
Lifting Machine |
Model No.: |
EGW15SA |
Size: |
41mm X 52mm X 5.5mm |
Weight: |
0.12kg |
Quality: |
ABEC-5 / ABEC-7 |
Stock: |
100pcs In Stock |
Origin: |
Wuxi Jiangsu |
Application: |
Lifting Machine |
HIWIN EGW15SA , EGW 15CA , EGH20SA Linear Guide Rail Block for Lifting Machine
EGW15SA Block Specification :
| FSK BEARING Model Number | EGW15SA |
| Part Name | Linear Guide Rail Block |
| Dimensions(mm)(d*D*b) | 41mm X 52mm X 5.5mm |
| Weight / Mass ( KG ) | 0.12kg |
| Precision Rating | ABEC-3 / ABEC-5 |
| Brand | HIWIN / FSKG / KBE / OEM / Any Brand |
| Original Country Show | TAIWAN ( HIWIN ) |
EGW15SA Block Drawing
EGW15SA Block Photos :
Same Series Other Blocks We Do
| Model | Component Dimensions | Block Size | ||||||||||||||
| (mm) | (mm) | |||||||||||||||
| H | H1 | N | W | B | B1 | C | L1 | L | G | M | K1 | T | T1 | H2 | H3 | |
| EGW 15SA | 24 | 4.5 | 18.5 | 52 | 41 | 5.5 | - | 23.1 | 40.7 | 5.7 | M5 | 14.8 | 5 | 7 | 5.5 | 6 |
| EGW 15CA | 26 | 39.8 | 57.4 | 10.15 | ||||||||||||
| EGW 20SA | 28 | 6 | 19.5 | 59 | 49 | 5 | - | 29 | 50.6 | 12 | M6 | 18.75 | 7 | 9 | 6 | 6 |
| EGW 20CA | 32 | 48.1 | 69.7 | 12.3 | ||||||||||||
| EGW 25SA | 33 | 7 | 25 | 73 | 60 | 6.5 | - | 35.5 | 61.1 | 12 | M8 | 21.9 | 7.5 | 10 | 8 | 8 |
| EGW 25CA | 35 | 59 | 84.6 | 16.15 | ||||||||||||
| EGW 30SA | 42 | 10 | 31 | 90 | 72 | 9 | - | 41.5 | 71.5 | 12 | M10 | 26.75 | 7 | 10 | 8 | 9 |
| EGW 30CA | 40 | 70.1 | 100.1 | 21.05 | ||||||||||||
| Model | Bolt Size | Dynamic Load | Static Load | Allowable Static Moment | Masss | |||
| (mm) | C(kN) | C0(kN) | MR | MP | MY | Block | Rail | |
| (kN-m) | (kN-m) | (kN-m)) | (kg) | (kg/m) | ||||
| EGW 15SA | M3×16 | 5.35 | 9.4 | 0.08 | 0.04 | 0.04 | 0.12 | 1.25 |
| EGW 15CA | 7.83 | 16.19 | 0.13 | 0.1 | 0.1 | 0.21 | ||
| EGW 20SA | M5×16 | 7.23 | 12.74 | 0.13 | 0.06 | 0.06 | 0.19 | 2.08 |
| EGW 20CA | 10.31 | 21.13 | 0.22 | 0.16 | 0.16 | 0.32 | ||
| EGW 25SA | M6×20 | 11.4 | 19.5 | 0.23 | 0.12 | 0.12 | 0.35 | 2.67 |
| EGW 25CA | 16.27 | 32.4 | 0.38 | 0.32 | 0.32 | 0.59 | ||
| EGW 30SA | M6×25 | 16.42 | 28.1 | 0.4 | 0.21 | 0.21 | 0.62 | 4.35 |
| EGW 30CA | 23.7 | 47.46 | 0.68 | 0.55 | 0.55 | 1.04 | ||
FSK Bearing Company Advantages:
(1) We have first-class testing equipment to detect bearing various data parameters and control the quality of the bearing.
Whenever bearings must first detected whether the quality is qualified and the unqualified bearing will be eliminated directly.
So we can get the trust of a large number of customers, and supply them for several years.
(2) We have our own R & D capabilities, to help customers solve the problem of non-standard bearings.
We can also according to customer requirements change their own mark.
(3) Price, our manufacture ensure that our prices across China are quite competitive.
It is better for you to compare prices and quality among suppliers.
But everyone knows you can not buy the highest quality products with the lowest price,
but our product is the best quality if you use equal price.
FSK Cooperation Details
Delivery:
For Small weight or ungent ,we send by express UPS,DHL,FEDEX, or EMS,china post with Thracking number
For max production , we will ship by sea/air.
Payment Item:
TT, 30% deposit , 70% before shippment.
L/C At Sight
Paypal Or Western Union In advance
Service:
Trade Assurance
Payment Protection
Timely Delivery Guaranteed
Product Qualtity Protection
About FSK Bearing Company
Shipping and Delivery
HIWIN EGW15SA , EGW 15CA , EGH20SA Linear Guide Rail Block for Lifting Machine , Get Cheap Price from China Bearing Factory Now !
